SPM-500

MODEL UNIT SPM - 500
INJECTION UNIT
SHOT WEIGHT (GPPS) gms 1385 1590 1810
THEORETICAL DISPLACEMENT cc 1539 1767 2011
INJECTION PRESSURE bar 2039 1792 1587
INJECTION RATE cc/sec 307 349 394
INJECTION SCREW STROKE mm 425 425 425
SCREW DIAMETER mm 75 80 85
SCREW L/D RATIO 23 21.4 20.1
SCREW SPEED rpm 150 150 150
PLASTICIZING RATE (GPPS) gm/sec 64.7 73 89.2
NOZZLE DEPTH mm 65 65 65
NOZZLE HOLDING FORCE KN 73
HEATING POWER kw 38
NO OF HEATING ZONE 5+1
CLAMP UNIT
MOULD CLAMPING FORCE KN 5000
MOULD OPENING STROKE mm 790
MOULD HEIGHT MIN / MAX mm 350/800
MAX. DAYLIGHT mm 1590
DISTANCE BETWEEN TIE ROD mm 820X820
PLATEN SIZE (H X V) mm 1200X1200
EJECTOR STROKE mm 220
EJECTOR FORCE KN 75
GENERAL
ELECTRIC MOTOR kw 55
CONNECTED POWER kw 93
TOTAL OIL CAPACITY Ltr 700
WATER REQUIREMENT (Inlet temp. 29 deg) Ipm 100
MACHINE DIEMENSION (L X W X H) Mtr 9.2X2.4X3.2
MACHINE WEIGHT kg 18500
